LED Shoebox Light 140W LED Area Light Outdoor LED Shoebox Light LED Shoebox Pole Light LED Parking Lot Light Fixtures LED Shoebox Light Fixture(6SB Series)
Description
Green Inova‘s 6th Generation slim profile LED shoebox light is designed to replace metal halide/high pressure solid shoebox. It can replace 250W-1000W metal halide fixture with lighting efficacy up to 126lm/w, over 70% energy saving.
Constructed with high quality die-casting aluminum heat sink features excellent heat dissipation, LED TC<75°C (25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@25°C.
In addition, this fixture offers multiple options to meet any need-e.g. electrical controls, optics, mounting possibilities, and surge protection, etc.
The 6SB series is IP65 rated, suitable for wet locations, the fixture is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.
Specification Summary
| Typical Model | 6SB140L40B2I | 6SB140L45B2I | 6SB140L50B2I |
| Power (W) | 140W | 140W | 140W |
| Color Temperature (CCT) | 4000K | 4500K | 5000K |
| Lumen Output (LM) | 16,000 | 16,000 | 16,000 |
| Efficacy (lm/W) | 123 | 123 | 123 |
| Input Voltage (V) | 100-277V, 347-480V available | ||
| Power Factor | >90% | ||
| THD | <20% | ||
| CRI | 73 | ||
| Optics | High Purity Anodized Aluminum Reflector | ||
| Distribution | Type III, Type V available | ||
| LED Class | UL Listed: LM80 | ||
| Driver Class | UL Listed: Class II | ||
| Controls | Photocell/Dimming/Motion sensors available | ||
| Environment | Wet Locations | ||
| Operating Temperature | –25°C to +45°C | ||
| Certifications | UL/cUL, LM79, LM80 | ||
| L70 Lifetime (hours) | 150,000 hours per L70 TM-21@ 25°C | ||
| Warranty | 6-year limited system warranty standard | ||
Features
Controls
• High system efficacy up to 126 LPW
• Class II UL listed driver
• Die-casting aluminum heat sink, LED TC<75°C (@25°C ambient)
• Excellent thermal management ensures long lifespan
• Tempered and shatter-resistant glass for durability
• S316 stainless steel screws, stronger ability to resist corrosion
• 10kA surge protection as standard
• Various mounting brackets for different applications
• Environmentally friendly surface finish
• Multiple optics allowing flexible designs
• Various controls to achieve high energy saving
• Reduces energy consumption over 70%
Housing & Finish
• Die-casting aluminum heat sink
• Tempered and shatter-resistant glass
• High purity anodized Aluminum reflector
• Bronze finish standard, black and white optional
• RAL & custom colors available
Optics
• Type III
• Type V
Electrical
• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non-dimming or 0-10V dimming
• Surge protection
• 0-10V dimming optional
• Photocell sensor optional
• Dimming motion sensor optional
• Remote controller optional
Mounting Bracket
• Slip Fitter Bracket
• Trunnion Bracket
• Slip Fitter Bracket
• Yoko Bracket
Compliance
• DLC Premium
• UL/cUL listed
• UL 1598 suitable for wet locations
• LM79, LM80 test reports
• CE & RoHS available
Ratings
• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –25°C to +45°C
Warranty
• 6-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.
Advantages
Mounting Brackets Options
Slip Fitter
Straight Arm
Trunnion Bracket
Yoko Bracket
Installation Options
Slip Fitter
Straight Arm
Trunnion Bracket
Yoko Bracket
Applications
• Outdoor lighting
• Parking lots, stadiums, automotive dealerships, roadways, parks, etc.
The 6SB series is ideal for parking lots, stadiums, automotive dealerships, roadways, schools, etc.
Projects that feedback from our customers
Location: Mississippi, USA
Product: 140W LED Shoebox Light
Click to view other wattages
