200W LED linear high bay shop lights 1×4 high bay lighting warehouse lighting fixtures workshop lighting industrial high bay LED lighting 4ft version with PC cover or 80 degree lens (2LHB Series)
Description
Green Inova®‘s Gen2 Linear LED High Bay improved with exceptional 130LPW output, is the energy efficient and maintenance free replacement or upgrade choice for existing HID metal halide and fluorescent high bay light fixtures, with similar dimension and shape.
Utilizing an integrated sheet steel for heat sink and thermal control, LED TC<75°C (@ 25°C ambient). Excellent thermal management ensures long life, 150,000 hours per L70 TM-21@ 25°C.
The fixture has a separated driver box on the side and is designed for easy maintenance with driver access. Two fixtures can also be connected by bracket and wires to be one unit, easy for inventory management.
In additon, this fixture offers multiple options to meet any need – e.g. electrical controls, optics, mounting possibilities, and wire guard, etc.
Specification Summary
| Typical Model | 2LHB200BL40W3F | 2LHB200BL45W3F | 2LHB200BL50W3F |
| Power (W) | 200W | 200W | 200W |
| Color Temperature (CCT) | 4000K | 4500K | 5000K |
| Lumen Output (LM) | 24,900 | 24,900 | 24,950 |
| Efficacy (lm/W) | 132 | 132 | 132 |
| Voltage (V) | 100-277V (347-480V available) | ||
| Power Factor | >90% | ||
| THD | <20% | ||
| CRI | ≥70 | ||
| Optics | Frosted Cover (Clear Cover available) | ||
| Beam Angle (°) | 120° Std. ( Medium Lens 82°, and Aisle Lens 40° available) | ||
| Dimensions (in) | 45.66"x13.77"x1.65" | ||
| Driver Class | UL Listed: Class II | ||
| Operating Temperature(°C) | –20°C to +50°C | ||
| IP Rating | IP54 | ||
| Environment | Indoor | ||
| Certificates | cULus, LM79, LM80 | ||
| Controls | Dimming, Sensors, Emergency battery back-up available | ||
| Life (L70, H) | 150,000 hours per L70 TM-21@ 25°C | ||
| Warranty | 5-year limited system warranty standard | ||
Features
Controls
• High system efficacy up to 130 LPW
• Class II UL listed driver
• Cold rolled steel heat sink, LED TC<75°C (@ 25°C ambient)
• Excellent thermal management ensures long life
• Unique modular design allows for ease of field maintenance
• Innovative high-tech design combines form with function
• Lightweight and enhanced performance
• Environmentally friendly powder coatings
• Multiple optics allowing for flexible designs
• Various controls available allowing for further energy savings
• Reduces energy consumption over 70%
Electrical
• 100-277V, and 347-480V available
• System power factor >90% and THD <20%
• LED driver with non–dimming or 0-10V dimming
Housing & Finish
• Cold rolled steel
• High gloss baked white matte powder painted after fabrication
• Painted white finish
• RAL & custom colors available
• 0-10V dimming optional
• Photocell sensor optional
• On/Off motion sensor optional
• Dimming motion sensor optional
• Remote controller optional
• Emergency back-up available
Accessories
• Wire guard optional
Compliance
• DLC Premium
• cULus, file#E352762
• UL 1598 suitable for damp locations
• LM79, LM80 tests and report
• CE & RoHS
• SAA
Ratings
• 150,000 hours per L70 TM-21@ 25°C
• Temperature Rated at –20°C to +50°C
Warranty
• 5-year limited system warranty
Optics
• Wide Beam(120°) : frosted or clear cover options for general or open areas
• Medium Lens (82°): medium lens for higher ceillings
• Aisle Lens (40°): aisle lens for applications with aisles or racks
NOTE: 310W is not available to add lens*
Lens Selection by Application
| Optic Type | Beam Type | Mounting Height | Space Type |
| 120° Frosted Cover | Wide | 10-30ft (3-9m) | Open Area |
| 120° Clear Cover | Wide | 10-30ft (3-9m) | Open Area |
| 82° Medium Lens | Medium | 10-60ft (3-18m) | Open Area |
| 40° Aisle Lens | Narrow | 20-60ft (6-18m) | Aisle or rack at low to high |
Dimensions
80W / 100W (24.01"x13.77"x1.65")
150W / 200W (25.19"x17.71"x1.65")
200W / 310W (45.66"x13.77"x1.65")
Note:
*200W has two versions/sizes:
2LHB200: 25.19x17.71x1.65 in, 2FT.
2LHB200B: Bigger, 45.66x13.77x1.65 in, 4FT.
Installation Options
• Standard Cable Hanging (Std.)
• Chain mounting (sold separately)
• Surface mount bracket (sold separately)
• Pendant mount brackets (sold separately)
1. Cable Mount (Standard)
2. Chain Mount
3. Surface Mount
4. Pendant Mount
* Accessories included
* Chain sold separately
* Surface bracket sold separately
* Pendant mount kits sold separately
* Pipe is not offered
Advantages of Gen.2 LED Linear High Bay
• Integrated heat sink design features excellent heat dissipation performance.
• Easy to replace driver with driver compartment on the side (Design of driver compartment on the side replaces driver easily). Most linear high bay lights come with driver compartment on the top or bottom. It is not good for the driver to dissipate heat as the heat generated by the LED goes up if the driver compartment is on the top.
• Integrated heat sink design helps cut the cost, heat sink edges can be used to reflect the light. No extra reflectors needed.
• Separate PC cover or lens for every single PCB line, compared to public design making entire light share one big cover, greatly improve the light efficacy and cut the cost.
• Separate PC cover or lens for each PCB line can improve the lighting efficiency and cut the cost, while other linear high bay lights are with entire PC cover.
• It is easy to do the wiring as we design a movable cover behind the driver compartment. Customers can open and wire easily if they do not want AC wire exposed.
• Using “V” hook for easy installation, height adjusting is available, more flexible.
Applications
• High and low bay lighting
• Aisles or open floor plan
• Warehouse, industrial, gymnasiums, sports areas, etc.
The 2LHB series LED high bay is ideal for a wide variety of applications and mounting heights, like warehouses, retail spaces, garages, gyms, sports areas , manufacturing facilities and work areas. etc.
