120V 12W LED Landscape Light with Spike (7BF Series)
Description
Green Inova ® ‘s 7th Gen. LED Bullet Flood light delivers exceptional illumination performance by using Latest LED Technology, efficacy up to 115 lm/w, and it can replace up to 150W metal halide, energy saving over 80%.
Sealed to keep out dirt, bugs and moisture, the luminaire is constructed with a precision die-cast aluminum housing and optical lens for a sleek appearance and maximum durability.
Specification Summary
| Typical Model | 7BF12L30BM | 7BF12L40BM | 7BF12L50BM |
| Power (W) | 12W | 12W | 12W |
| Color Temperature (CCT) | 3000K | 4000K | 5000K |
| Lumen Output (LM) | 1280lm | 1340lm | 1380lm |
| Dimensions (in) | φ4.406“. H:5.906” x D:2.323” | φ4.406“. H:5.906” x D:2.323” | φ4.406“. H:5.906” x D:2.323” |
| Voltage | AC 120V or AC 230V | ||
| Housing Finish | Bronze | ||
| LED | 2835 | ||
| CRI | 70 | ||
| Certificate | ETL | ||
| Beam Angle (°) | 40° | ||
| Fixture Material | Die-Cast Aluminum | ||
| IP Rating | IP65 | ||
| Operating Temp. | From -30°C to +40°C | ||
| Average Lifespan | 50,000 hours | ||
| Warranty | 5-year limited | ||
Features
• AC 120V or AC 230V
• 40° Beam
• Excellent thermal management for a long life
• IP65 rated for both outdoor and indoor use
• ½” NPT threaded arm with locking swivel
Optics
• Distribution Medium : 40° for general areas
Housing & Finish
• Die-casting Aluminum body
• Tempered and optical lens for durability
• Bronze finish standard, black and white optional
• RAL & custom colors available
Accessories
• Shroud
• Lamp holder cover
• Ground stake
Warranty
• 5-year limited system warranty
* Please refer to Green Inova’s warranty term for complete information.
Dimension
Installation Options
Wall mount and ground mount are available.
Wall Mount
Ground Mount
Applications
• Indoor & outdoor lighting
• Landscape lighting
• Building lighting
• Flag pole lighting
The IP65 rated fixture, can be surface mounted directly to electrical boxes or posts with a 1/2” threaded bushing. Available with spot and flood optics making it ideal for an array of commercial and outdoor applications, including landscape, structural accent, building details and flag pole lighting.
